Application:
This model is mainly used for passport, hard cover book.
Main Features:
1. The working speed is 500-1000 PCS/hour
2. The distance of the sewing could be adjusted.
3. This machine could apply in notebooks, brochure and exercise books.
4. This machine use high sensitivity FOS automatic sewing machine, no need the foot switch.
Model | MF-SFM470A |
Power Supply | 380V 50Hz/ 60Hz/ 5.2kW |
Binding thickness | Max 3mm (customed 5mm) |
Air Compressor | 1.5KW |
Air Pressure | 6-8Pa |
Max Paper Size | 600*470mm |
Work Speed（n/hour） | 500-1000 (Times/Hour) |
Machine Dimensions(L×W×H) | 2830×1850×1580mm |
Machine Weight | 1000kg |
