Machine Description
Semi-automatic Three knife Trimmer MF-STM300 adopts servo drive system and touch screen operation. Fully automatic knife adjustment, high cutting precision, safe and efficient. It can flexibly change the version when cutting small batches, and it is convenient and quick to change jobs.
主要技术参数 Technical Parameters 型号 Model No. MF-STM300 最大裁切尺寸（mm） Max. Cutting Size (mm) 420 * 300 最小裁切尺寸（mm） Min. Cutting Size (mm) 80 * 80 最大裁切高度（mm） Max. Cutting Height mm) 100 最低裁切书本高度（mm） Min. Cutting Book Height (mm) 8 最小单体裁切高度（mm） Min. Single Cutting Height (mm) 5 最高裁切速度（times/m） Cutting Speed (times/m) 28 电机总功率（KW) Power (KW) 6.2 气 压（Pu） The pressure（Pu） 6 外形尺寸（mm) Overall Dimension (L*W*H / mm) 2800*2370*1700 机器重量(KG) Machine Weight (Kg) N.W 2800 G.W 3000KG 机器包装尺寸 Packaging Size L2280x W1780xH1980mm
Main features 1. 主机采用伺服传动系统，可精准配合机器其它部位的运行精度、及扭力的保护设定，很大的提高机器的裁切精度及使用寿命。 Machine adopts a servo transmission system, which can accurately match the operation accuracy of other parts of the machine and the protection of torque setting, greatly improving the cutting accuracy and life span of the machine. 2. 机器设有单人操作模式和多人操作模式，可自由转换。 The machine has a single-person operation mode and multi-person operation mode, which can be freely converted. 3. 触摸屏可完成全自动调节前刀、侧刀、机械排书手的规格尺寸。 Use touch screen can fully automatically adjust the specifications of the front knife, side knife and mechanical book arranger. 4. 配备前刀快速装刀装置，侧刀快速装刀装置。 Equipped with a front knife quick knife installation device and side knife quick knife installation device. 5. 各门设有保护开关，机罩门打开时机器自动停止运行保护。 Each door is equipped with a protective switch, and the machine automatically stops running when the cover door is opened.
